eBPF: Preventing Garbage HTTP Payloads When Reading Kernel Scatter-Gather Buffers

Recently someone on our team opened a traffic snapshot and found an HTTP request that was captured with our eBPF capture agent, nettap. Our protocol dissector parsed most of the response correctly, but that correctness ended once the response headers were processed. What they ended up with was a recording of an HTTP request/response where the response body was just an incorrect collection of garbage binary data when it should have been JSON text.

But here’s the kicker: it only did this some of the time and didn’t negatively affect the application being monitored (i.e. the app either received or sent correct HTTP payloads). This didn’t help me isolate the problem as strictly an eBPF problem, a protocol dissector problem, or both.

It turned out to be an eBPF problem after all: the TCP probes were incorrectly (or rather, incompletely) processing and reading the kernel’s scatter-gather struct iov_iter buffers.

What Is Available to TCP eBPF Probes?

nettap captures plaintext TCP payloads by attaching BPF fentry and fexit trampolines to tcp_recvmsg and tcp_sendmsg, then reading the application’s buffer directly out of the struct msghdr the kernel was given. For tcp_recvmsg all of the heavy lifting was in the fexit probe since you get both the function call arguments AND its return value in a single eBPF program. The return value in this case is the number of bytes that were read. Pretty standard C stuff.

But what you have to remember is that tcp_recvmsg doesn’t use “just a buffer”, it uses msg->msg_iter, which is a struct iov_iter - an abstraction on top of “here is some data in memory, which is one of a few different types, you need to iterate over it to get the whole thing”. LWN’s introduction to the interface is a fantastic, plain-English writeup on what it’s for (and it makes perfect sense).

Here’s the shape of it as of v6.12, from include/linux/uio.h (just the important parts):

struct iov_iter {
    u8 iter_type;
    bool nofault;
    bool data_source;
    size_t iov_offset;
    union {
        struct iovec __ubuf_iovec;
        struct {
            union {
                const struct iovec *__iov;
                const struct kvec *kvec;
                const struct bio_vec *bvec;
                /* ... */
                void __user *ubuf;
            };
            size_t count;
        };
    };
    union {
        unsigned long nr_segs;
        u8 folioq_slot;
        loff_t xarray_start;
    };
};

The problem with this and writing eBPF programs is that you can’t use the kernel APIs for actually iterating over this data in a type-agnostic way. If it’s not an exposed kfunc you can’t use it. So what does that mean for processing this data structure?

First, the union doesn’t guarantee type safety; you have to know which to use based on the iter_type struct field which holds the value of a specific enum iter_type (all of this is in include/linux/uio.h by the way). Pre-5.14 kernels use unsigned int type instead of u8 iter_type, but it still holds the value of an enum iter_type. For this exercise, we’re only focusing on __iov and ubuf from the struct shown above (again, kernel version does matter so pay attention to that).

Second, the thing you need to be mindful of in this situation (or any eBPF program, really) is that on fexit, the kernel may have (read: probably has) already processed and consumed the iterator, rendering it completely useless. You can’t go backwards once it’s been advanced. In other words, at fexit time, if the kernel has processed more than one segment, you’re only going to know where you ended up, not where you started.

Where the original implementation got lucky was in handling TCP reads/writes that could fit the entire request/response in a single segment. This, of course, broke when spanning more than one segment and we ended up with a return value n being larger than what the last segment buffer actually was.

See where I’m going? Buffer over-read. And that’s how we ended up with the garbage binary data.

flowchart TD
    A[tcp_recvmsg returns n bytes] --> B{Iterator spans<br/>one segment?}
    B -->|Yes, nr_segs == 1| C[Read n bytes from<br/>the single buffer]
    C --> D[Correct payload]
    B -->|No, multiple segments| E[Read n bytes from<br/>last segment only]
    E --> F[n larger than<br/>that segment's length]
    F --> G[Buffer over-read:<br/>garbage trailing bytes]

So how did we run into this? We have a set of demo applications implemented in several different programming languages and the ones that hit this the most, if not consistently: the Node apps. I didn’t dig into the “why” on the Node-side, I just left it at that and focused on the fix.

Reminder: Kernel Versions Matter

Before going any further, let’s talk about kernel versions and portability. Remember that we have to check the iter_type value in order to know what struct field to actually use. The problem is that those values are not stable across kernel versions. And I don’t mean “they were renamed once in 2015”; I mean they have changed a few times:

Kernel	ITER_IOVEC	ITER_KVEC	ITER_BVEC	ITER_UBUF
<= 5.13	4 (bitmask)	8	16	n/a
5.14 - 5.19	0	1	2	n/a
6.0 - 6.4	0	1	2	6
6.5 - 6.6	0	1	2	5
6.7 - 6.11	1	3	2	0
6.12+	1	3	2	0

The takeaway here is that ITER_UBUF is relatively new and was added in v6.0. ITER_PIPE was deleted entirely in 6.5. The entire enum was reordered with ITER_UBUF being first in 6.7, and ITER_FOLIOQ being added in 6.12. On kernels 5.14 through 6.6, 0 means ITER_IOVEC. On 6.7 and later, 0 means ITER_UBUF.

Yeesh… so how do we handle this?

An eBPF probe that hardcodes the assumption that ITER_IOVEC is equal to 0 will, on any reasonably current kernel, take a single userspace char* and dereference it as a struct iovec* (it absolutely is not). Fortunately, though, nothing crashes because bpf_probe_read_user() assumes the given pointer is inherently unsafe, so reads are safe. But in this case, it meant that we ended up reading garbage data, the exact failure mode we were looking for in the first place.

This is where CO-RE really becomes a godsend. libbpf provides a couple of extremely useful functions for this specific sort of quagmire: bpf_core_enum_value_exists() and bpf_core_enum_value(). By leveraging the former, you can programmatically check if the enum value you want, like ITER_UBUF, actually exists. The latter lets you get the actual value from the machine on which your application is running.

The same story applies to struct field renames. In this particular case, struct iov_iter would have a const struct iovec* member named either iov or __iov, and potentially at different offsets, depending on the kernel version (6.4 is where it picked up the underscores). CO-RE handles this one too, but the mechanism is a bit weirder. You declare a “flavor” of the struct that contains only the fields you care about, then let bpf_core_field_exists() decide which one applies to the kernel you happen to be running on:

// IMPORTANT: CO-RE flavors only work if you suffix the struct name with *THREE* underscores
struct iov_iter___6_x_old {
    const struct iovec* iov;
} __attribute__((preserve_access_index));

static __always_inline const struct iovec* get_iovec(const struct iov_iter* iter)
{
    // 6.4 and later renamed .iov to .__iov
    if (bpf_core_field_exists(iter->__iov))
        return BPF_CORE_READ(iter, __iov);
    else if (bpf_core_field_exists(((const struct iov_iter___6_x_old*)iter)->iov))
        return BPF_CORE_READ((const struct iov_iter___6_x_old*)iter, iov);

    return NULL;
}

flowchart LR
    A[struct iov_iter] --> B{Field __iov<br/>exists?}
    B -->|Yes, 6.4+| C[BPF_CORE_READ<br/>iter, __iov]
    B -->|No| D{Flavor field .iov<br/>exists?}
    D -->|Yes, pre-6.4| E[BPF_CORE_READ<br/>flavor, iov]
    D -->|No| F[return NULL]

That three underscore business is not a typo and it is not optional. Use two and libbpf treats your flavor as a completely unrelated type: no relocation, no warning, no error, just garbage data again. Andrii Nakryiko’s CO-RE reference guide is about the only place I’ve ever seen that documented, and it’s an incredible reference on all of this. Read it front to back if you spend any time in this space.

(Another) Reminder: Kernel Versions Matter!

Turns out, enum variations between kernel versions were just one of the compatibility issues I ran into.

The other? Changes in the function signature itself between versions. An fentry program written against tcp_recvmsg’s signature from one kernel version will fail to attach on another, because the arguments no longer agree with the system’s BTF prototype. Here’s how that signature has drifted over time:

// pre-5.19 kernels
int tcp_recvmsg(struct sock *sk, struct msghdr *msg, size_t len, int nonblock, int flags, int *addr_len);

// 5.19 and 6.x kernels
int tcp_recvmsg(struct sock *sk, struct msghdr *msg, size_t len, int flags, int *addr_len);

// 7.1 kernels
int tcp_recvmsg(struct sock *sk, struct msghdr *msg, size_t len, int flags);

Dealing with this is trivial, but not on the surface. First, you need to define fentry and fexit programs for each of those function signatures:

SEC("fentry/tcp_recvmsg")
int BPF_PROG(tcp_recvmsg_fentry_nonblock, struct sock* sk, struct msghdr* msg, size_t len,
             int nonblock, int flags, int* addr_len);

SEC("fentry/tcp_recvmsg")
int BPF_PROG(tcp_recvmsg_fentry, struct sock* sk, struct msghdr* msg, size_t len,
             int flags, int* addr_len);

SEC("fentry/tcp_recvmsg")
int BPF_PROG(tcp_recvmsg_fentry_no_addr_len, struct sock* sk, struct msghdr* msg, size_t len,
             int flags);

Then, prior to attaching your programs, use the system’s BTF information to help you prune the incompatible ones. Straightforward in Go using bpf2go and github.com/cilium/ebpf with a little bit of legwork:

import (
    "github.com/cilium/ebpf"
    "github.com/cilium/ebpf/btf"
)

func removeIncompatiblePrograms(spec *ebpf.CollectionSpec) {
    // load the system BTF (usually at this path)
    kernelBTF, err := btf.LoadSpec("/sys/kernel/btf/vmlinux")
    if err != nil {
        log.Fatalf("cannot load BTF: %w", err)
    }

    var fn *btf.Func
    if err := kernelBTF.TypeByName("tcp_recvmsg", &fn); err != nil {
        log.Fatalf("tcp_recvmsg not found in kernel BTF: %v", err)
    }

    proto, ok := fn.Type.(*btf.FuncProto)
    if !ok {
        log.Fatalf("tcp_recvmsg BTF type is %T, expected *btf.FuncProto", fn.Type)
    }

    // depending on the param count, remove the incompatible ones
    switch len(proto.Params) {
    case 6:
        // keep: with nonblock
        delete(spec.Programs, "tcp_recvmsg_fentry")
        delete(spec.Programs, "tcp_recvmsg_fentry_no_addr_len")
    case 5:
        // keep: removed nonblock, with addr_len
        delete(spec.Programs, "tcp_recvmsg_fentry_nonblock")
        delete(spec.Programs, "tcp_recvmsg_fentry_no_addr_len")
    case 4:
        // 7.1+
        delete(spec.Programs, "tcp_recvmsg_fentry_nonblock")
        delete(spec.Programs, "tcp_recvmsg_fentry")
    }
}

// *bpf.YourProjectObjects is a generated name done by bpf2go that contains all programs, maps, and global
//vars. this is just for demonstration
func linkTracingProbes(objects *bpf.YourAppObjects) {
    name := "fentry/tcp_recvmsg"

    // try to attach all the variants. we'll go with the first one that succeeds (the one that wasn't removed)
    variants := []*ebpf.Program{
        objects.TcpRecvmsgFentryNonblock,
        objects.TcpRecvmsgFentry,
        objects.TcpRecvmsgFentryNoAddrLen,
    }

    for _, prog := range variants {
        if prog == nil {
            continue
        }

        opts := link.TracingOptions{
            Program:    prog,
            AttachType: ebpf.AttachTraceFEntry,
        }

        //
        if l, err = link.AttachTracing(opts); err == nil {
            // success
            break
        }

        // it failed, wrong function argument count, try the next
    }
}

Revisiting the Initial Implementation

The initial implementation seemed correct on the surface (at least for the majority of the cases we were able to observe and test against), so we shipped it. The eBPF programs that pushed TCP data from the kernel to our protocol dissectors were essentially just doing a simple pass over struct iov_iter assuming a couple of known differences between versions we had been directly exposed to. In a nutshell, we’d look for the iter_type value, check that against a constant value we probably knew, then read the struct field we needed to use.

Once we had the iter_type we needed to know, we assumed that a single segment (i.e. nr_segs == 1) was Probably OK™ and just read whatever data we could based on the return value we observed (the number of bytes read/written).

In hindsight, assuming reads/writes were small enough to fit into a single buffer segment was a hacky, naive implementation, but it worked given the dataset we could test against at the time. We lacked exposure to kernel and application variations that would have surfaced the issue prior to release. But let’s be honest: unless you work for NASA, you likely go for a reliable set of compatibility rather than an exhaustive one, otherwise you’d never release anything.

It’s a simple fix: if it’s a struct iovec, iterate nr_segs times to read iov_len amount of data from each struct iovec*, offset from the initial struct iovec*. And that’s fine if the pointer hasn’t been advanced by the kernel by the time you read the data. But what if it did?

A quick note about state at fentry vs fexit (or kprobe and kretprobe if you aren’t using eBPF trampolines): things can change between the time you first see something and the time you last see something. This really isn’t an issue for fentry on tcp_sendmsg; it’s trivially handled because you have both access to the data before pointers are mucked with and a size_t that tells you how much data is there.

Handling tcp_recvmsg is a little different; a chicken/egg problem. You need the pointer to the start of the data in fentry, but you need the return value in fexit, the point at which the kernel has likely advanced pointers on you. In other words, don’t attempt to look at the data only at fexit time since the pointer you assume is the head of the list could be, and probably would be, pointing to the wrong data. In a nutshell, you need the unmodified pointer at fentry time but the return value at fexit time.

How can we solve this?

sequenceDiagram
    participant App as Application
    participant K as Kernel tcp_recvmsg
    participant FE as fentry probe
    participant TS as Task-local storage
    participant FX as fexit probe
    participant US as Userspace
    App->>K: recv() into iov_iter
    FE->>K: read iov_base / iov_len per segment
    FE->>TS: save unadvanced segments
    K->>K: copy data, advance iterator
    K->>App: return n bytes
    FX->>TS: load saved segments
    FX->>FX: bound total by n, MIN(remain, iov_len)
    FX->>US: send correct payload

Tracking Data Between fentry and fexit

One option for tracking a potentially volatile pointer value between fentry and fexit is to just use a BPF_MAP_TYPE_HASH or BPF_MAP_TYPE_LRU_HASH map. Key the data on the value of bpf_get_current_pid_tgid() and track whatever value you need for later. It’s a common pattern, it’s simple, and it works well.

A second approach, and the one that we opted for, is to use a specific type of map BPF_MAP_TYPE_TASK_STORAGE. These task-local storage maps provide space usable to eBPF programs that are specific to the current task. In other words, adding or reading to and from these maps automatically handles the task-specific key management shown above using bpf_get_current_pid_tgid(). Another, perhaps even more attractive attribute of these maps is that any entry for a task is automatically removed whenever the task itself ends. A pretty handy (and clean) approach to the problem. Here’s a trivial, dummy example of what that might look like:

struct task_data {
    void* something_to_track;
};

struct {
    __uint(type, BPF_MAP_TYPE_TASK_STORAGE);
    __uint(map_flags, BPF_F_NO_PREALLOC);
    __type(key, int);  // note: must always be 32-bit value
    __type(value, struct task_data);
} task_storage_map SEC(".maps");

SEC("fentry/some_kernel_func")
int BPF_PROG(handle_fentry, int first_arg, void* second_arg)
{
    struct task_struct* task = bpf_get_current_task_btf();
    struct task_data* data = bpf_task_storage_get(&task_storage_map, task, NULL, BPF_LOCAL_STORAGE_GET_F_CREATE);

    if (!data)
        return 0;

    // get the pointer to whatever you need to track for later
    data->something_to_track = second_arg;

    return 0;
}

SEC("fexit/some_kernel_func")
int BPF_PROG(handle_fexit, int first_arg, void* second_arg, int ret)
{
    // you have access to the return value at this point, so you can make decisions based on that

    // retrieve it
    struct task_struct* task = bpf_get_current_task_btf();
    struct task_data* data = bpf_task_storage_get(&task_storage_map, task, NULL, 0);

    if (!data)
        return 0;

    // data->something_to_track is a void* now accessible

    return 0;
}

Fixing tcp_recvmsg for Real

Now that we’ve covered the basic structure of the fentry and fexit handoff using task-local storage, let’s get back to fixing our initial, incorrect implementation. We’ll worry about tcp_sendmsg later; we don’t need the return value as the data size is one of the function arguments. We do, however, for tcp_recvmsg.

The basic approach for tcp_recvmsg is this: for nr_segs worth of struct iovec*, track their values for void* iov_base and __kernel_size_t iov_len. We’ll retrieve and use them in their original state during the fexit call. Otherwise, in the return, we might incorrectly process the fexit argument struct msghdr* as if its msg_iter.iov pointer were the start of the iterator and not its tail. I’ll intentionally leave out some of the more tricky/nuanced aspects of handling kernel version differences, but it might look like this:

// NOTE: we limit the number of segments we process to 32 to make sure the verifier doesn't think
// the loop is unbounded. From observations, though, *most* have just a single segment or a handful at max
#define MAX_ITER_SEGS 32

struct iovec_seg {
    void* iov_base;
    __kernel_size_t iov_len;
};

struct iovec_segs {
    __u32 nr_segs;
    struct iovec_seg segs[MAX_ITER_SEGS];
};

struct {
    __uint(type, BPF_MAP_TYPE_TASK_STORAGE);
    __uint(map_flags, BPF_F_NO_PREALLOC);
    __type(key, int);  // always 32-bit
    __type(value, struct iovec_segs);
} tcp_iovec_segs_map SEC(".maps");

SEC("fentry/tcp_recvmsg")
int BPF_PROG(nt_tcp_recvmsg_fentry, struct sock* sk, struct msghdr* msg, size_t len,
             int flags, int* addr_len)
{
    // TIP: some applications might only be peeking at data rather than consuming it, so unless
    // you want duplicated data in the end, add this to your code
    if ((flags & MSG_PEEK) == MSG_PEEK)
        return 0;

    struct iov_iter iter = BPF_CORE_READ(msg, msg_iter);

    // example: just iovec for now
    if (!is_iter_type_iovec(&iter))
        return 0;

    // get the version-dependent field
    const struct iovec* base_iov = get_iovec(&iter);

    // get our task-local storage to save the pointers for later
    struct task_struct* task = bpf_get_current_task_btf();
    struct iovec_segs* data = bpf_task_storage_get(&tcp_iovec_segs_map, task, NULL,
                                                   BPF_LOCAL_STORAGE_GET_F_CREATE);

    if (!data)
        return 0;

    data->nr_segs = iter.nr_segs;

    // see note on MAX_ITER_SEGS above
    for (int i = 0; i < MAX_ITER_SEGS; i++) {
        if (i >= data->nr_segs)
            break;

        // current
        const struct iovec* cur_iov = base_iov + i;

        // save to struct in task-local storage
        data->segs[i].iov_base = BPF_CORE_READ(cur_iov, iov_base);
        data->segs[i].iov_len = BPF_CORE_READ(cur_iov, iov_len);
    }

    return 0;
}

The work in fentry here is intentionally dumb and only tracks data. It’s in fexit where all of the heavy lifting for our implementation lives. At that point, we have all of the necessary information we need to consume the iterator’s underlying data and send that to userspace for further processing:

SEC("fexit/tcp_recvmsg")
int BPF_PROG(nt_tcp_recvmsg_fexit, struct sock* sk, struct msghdr* msg, size_t len,
             int flags, int* addr_len, int ret)
{
    // NOTE: checking return value is wise here - you can exclude failures
    if (ret <= 0)
        return 0;

    // NOTE: at this point you can do all kinds of things not covered by this post: port filtering (i.e. known
    // TLS ports), PID exclusions, etc.

    // pull it from task-local storage
    struct task_struct* task = bpf_get_current_task_btf();
    struct iovec_segs* data = bpf_task_storage_get(&tcp_iovec_segs_map, task, NULL, 0);

    // validity checks
    if (!data)
        return 0;

    // process and send to userspace
    const struct iovec* base_iov = (const struct iovec*)data->segs;

    // `ret` bytes remaining to process
    __u32 remain = ret;

    for (int i = 0; i < MAX_ITER_SEGS && remain > 0; i++) {
        if (i >= data->nr_segs)
            break;

        // current
        const struct iovec* cur_iov = base_iov + i;

        // how much of this segment should we read
        __u32 read_len = MIN(remain, BPF_CORE_READ(cur_iov, iov_len));

        // send something to userspace (this is only for example)
        struct tcp_data chunk = {
            .buf = (void*)BPF_CORE_READ(cur_iov, iov_base),
            .len = read_len,
        };

        send_to_userspace(&chunk);

        remain -= read_len;
    }

    return 0;
}

Don’t forget that the tcp_recvmsg return value carries the actual total number of bytes you need to read. This is important to remember because iov_len is the buffer’s capacity, not the size of the data written there. I know this because my first fix used iov_len directly, ignored the function return value entirely, and (shocker) still ended up with garbage trailing data. Silly mistake to have made in hindsight, but that’s why you see the remain count bookkeeping and MIN(remain, iov_len) size limit in the code above.

And there you have it. We’ve fixed the naive, single segment approach to one that handles them all correctly.

Final Notes

We only really discussed the ITER_IOVEC and ITER_UBUF types here and none of the others. We’ve intentionally left those out as unimplemented/unsupported for now, purely as a scope call. The 32-segment cap from earlier is in the same bucket: reads with more segments than that get their tail silently truncated, which is a known gap rather than something we’ve actually solved.

So if there’s a portable lesson buried in all of this, it’s that reading another process’s memory from inside the kernel is never as simple as “follow the pointer.” The pointer becomes a lie the moment the copy starts. The constant you compare it against could change meaning every couple of releases. And the length field you instinctively reach for first is the wrong one. Every single one of those failures is silent - nothing crashes, nothing logs, nothing fails a test. They just hand you a screenful of zeros and leave you to work out why. Which, eventually, we did.
